Thermo Cabs offers
extensive expertise in design, development and manufacture
of high quality power, control, instrumentation,
thermocouple extension/compensating and communication cables
conforming to Indian/international standards and customer
specifications. The products include:
|
|
LT (Low Tension) control cables (upto 1.1
KV) |
LT (Low Tension) power cables (upto 1.1 KV) |
Instrumentation, signal and data cables |
Thermocouple extension / compensating cables |
|
|
Used in interconnection of process control,
communication and panel control systems. |
Used in connection of power supply to residential,
commercial & industrial units. |
Used in data acquisition systems, computer
networking, PA systems, digital control/measuring &
communication systems. Specially designed to
transmit signals without any external interference. |
Used to extend thermocouple circuits from the sensor
to reference unit. |
|
|
PVC / XLPE insulated cables conforming to IS:1554-I
/ IS:7098-I, BS:6346, IEC:60502, BS:5467,
BS:7846 and Customer specific requirements
Generally manufactured with conductor sizes
1.5/2.5/4.0 sq.mm |
PVC / XLPE insulated cables conforming to IS:1554-I
/ IS:7098-I, BS:6346,
IEC:60502, BS:5467, BS:7846 and
Customer specific requirements
single core cables upto 1000 sq.mm;
multi core cables upto 400 sq.mm. |
Generally manufactured with conductor sizes
0.5/0.75/1.0/1.5 sq.mm.
Conforming to BS:5308-I & II, IEC-189, VDE 0815,
IEC:60227 BS:7846 and Customer
specific requirements |
Generally manufactured with conductor sizes 16, 18 &
20 AWG.
Conforming to IS:8784, BS:4937, IEC-584,
ANSI:MC:96.1, DIN, JIS and Customer specific
requirements |
|
|
Conductor: solid / stranded /
flexible copper (bare / tinned), circular / shaped,
copper / aluminium
insulation: PVC GP / HR; XLPE,
LSZH
inner Sheath: PVC GP / HR / FR /
FRLS; LSZH
armour (for armoured cables):
galvanised steel round wire / flat strip / steel
tape / double steel tape or aluminium wire
Braid: steel wire, copper wire
outer sheath: PVC GP / HR / FR /
FRLS; LSZH
|
Conductor: solid / stranded,
circular / shaped, copper / aluminium
insulation: PVC GP / HR; XLPE,
LSZH
inner Sheath: PVC GP / HR / FR /
FRLS; LSZH
armour (for armoured cables):
galvanised steel round wire / flat strip / steel
tape / double steel tape or aluminium wire
outer sheath: PVC GP / HR / FR /
FRLS; LSZH
|
Conductor: solid / stranded /
flexible copper (bare / tinned)
insulation: PVC GP / HR; PE, XLPE,
LSZH
shielding: individual & overall or
overall screen only by Al-mylar tape / copper tape /
copper wire braid
inner sheath: PVC GP / HR / FR /
FRLS; PE, LSZH
armour (for armoured cables):
galvanised steel round wire / strip / steel tape /
double steel tape
Braid: steel wire, copper wire
Outer sheath: PVC GP / HR / FR /
FRLS; PE, LSZH
|
Conductor: solid / stranded;
type: KX, VX, TX, JX, EX, SX/RX
insulation: PVC GP / HR; PE, XLPE,
LSZH
shielding: individual & overall or
overall screen only by Al-mylar tape / copper tape /
copper wire braid
inner sheath: PVC GP / HR / FR /
FRLS; PE, LSZH
armour (for armoured cables):
galvanised steel round wire / strip
Braid: steel wire, copper wire
outer sheath: PVC GP / HR / FR /
FRLS; PE, LSZH
|
|
|
|
|
 |
 |
|
|
|
